Doka Framax

The Doka Framax System is an innovative panel formwork solution that allows for fast and effective forming.

APL has extensive experience in the buying, refurbishing, hiring and sale of the Doka Framax System, an innovative panel formwork solution that allows for fast and effective forming.

APL carries out all aspects of repair and refurbishment for the Doka Framax system in our own factory in the west midlands – this means to control, and high standards are guaranteed.

Framax

The steel Framax panels are an easily movable crane wall formwork system used in large-volume construction.

Features & Benefits

  • Allow a pour rate of 80kn/sqm
  • Rigid connection with levelling locks
  • Up to 40 m2 of formwork assembly
  • Can be moved using a crane
  • Completely galvanized frame

Framax Panels come in 5 widths: 3 heights and 2 extra large panels.

Panel Widths0.3m | 0.45m | 0.6m | 0.9m | 1.35m
Panel Heights1.35m | 2.7m | 3.3m
Extra-large
Steel Panels
240cm wide x 270cm high
240cm wide x 330cm high
A wide variety of Doka panels.

Panels in stock, ready to go.

Alu-Framax

Alu-Framax lightweight aluminium all formwork panels allow a pour rate of 60kn/sqm.

Due to the light weight of the panels, they can be installed with or without a crane.

Features & Benefits

  • Height and width can be adjusted in 15-cm increments.
  • 60kn/sqm pour rate.

Alu-Framax Panels are available in five widths and two heights of the panel,

Panel Widths0.90m | 0.75m | 0.60m | 0.45m | 0.30m
Panel Heights0.90m | 2.70m
